Galileosky 5.0
Galileosky 5.0 is the flagship of the Galileosky line due to the highest functionality and reliability, tested by specialized laboratories in Russia, Kazakhstan, Ukraine, Slovakia. The device has a CE certificate. The device has the ability to connect up to 16 fuel level sensors to the digital interface RS485. Can be installed on a variety of modes of transport.
Server Integration
| Server IP | 116.203.105.226 | |
| Port | 6034 | |
| Protocol | adm |
General information
| Purpose | Vehicle | |
| Installation | Professional |
Housing
| Weight | 300 g (10.58 oz.) | |
| Size | 104x72x28 mm (4.09x2.83x1.1 in) | |
| Waterproof class | IP54 |
GNSS Location
| External antenna (GNSS) | yes | |
| GPS | yes | |
| GLONASS | yes |
Connectivity
| Cellular network type | GSM 900/1800 | |
| External antenna (Connection) | yes | |
| Cellular network generation | 2G |
Interfaces
| 1-Wire interface | Yes | Supported |
| RS232 interface | Yes | Supported |
| Number of RS232 interfaces | 1 | |
| RS485 interface | Yes | Supported |
| Number of outputs | 4 | |
| Number of inputs (all types) | 8 | |
| ACC/Ignition input | Yes | Supported |
| Discrete inputs | Yes | Supported |
| Analog inputs | Yes | Supported |
| Impulse inputs | Yes | Supported |
| Frequency inputs | Yes | Supported |
| Outputs | Yes | Supported |
Hardware features
| Battery capacity | 600 mAh | |
| Built-in battery | Yes | Supported |
| Emergency button | Yes | Supported |
| Accelerometer | yes |
Hardware extras
| Emergency button | Yes | Supported |
| Fuel level sensor reading | Yes | Supported |
| Driver ID reading | Yes | Supported |
| External temperature sensor reading | yes | |
| Voice communication | yes |
Tracking features
| Tracking modes | Continuous | |
| Location by Cell ID | Yes | Supported |
| Smart power consumption | Yes | Supported |
Events monitoring
| Input change | Yes | Supported |
| Car crash | yes | On Request |
| Antenna cut off | yes | On Request |
| Towing | yes | On Request |
Self monitoring
| Network signal level | Yes | Supported |
| GNSS signal level | Yes | Supported |
| GNSS satellites fixed | Yes | Supported |
| GNSS HDOP | Yes | Supported |
| External power source voltage | Yes | Supported |
| Internal battery level | Yes | Supported |
CAN/OBDII reading
| CAN/OBDII reader type | Yes | Supported |
| CAN/OBDII parameters | Fuel level, fuel consumption, engine RPM, throttle position, speed, coolant temperature and other |
Remote management
| Server connection setup over SMS | Yes | Supported |
| Remote device configuration | Yes (over GPRS) | Supported |
| Remote outputs control | Yes (over GPRS) | Supported |
Certification
| CE | yes | |
| EAC | yes |
